Product Introduction
Product Overview
Product
The Automatic Winding Machine (Automatic Take-Up Winding Machine) is an automated winding equipment launched by Huafang Machinery, specially designed for applications such as rope coil sealing and spool winding. The machine adopts PLC programmable logic controller as the core control unit, achieving fully automatic operation without continuous manual intervention, greatly improving the efficiency and consistency of winding operations.
In terms of core drive, the machine is equipped with a 100W motor, compatible with 220V power supply, featuring low power consumption and economical operating costs. The total machine weight is 220kg, with a solid and stable structure ensuring smooth operation during the winding process and reducing vibration that may affect winding accuracy. The machine dimensions are 60×60×160cm, with a small footprint that allows flexible deployment in various production workshops, especially suitable for environments with limited space.
In terms of production capacity, the machine can reach an output of 200 units (depending on material specifications and process requirements), meeting small to medium batch continuous production needs. The machine comes with a 1-year warranty, and mechanical test reports and video factory inspection are available to ensure reliable quality and performance standards.
The machine is positioned in the automatic winding equipment field and can be widely used for automatic take-up winding of rope coils and various spools, making it an ideal choice for improving automation levels in post-treatment packaging and winding processes.
Features
| Feature |
Detailed Description |
| PLC Automatic Control |
Core component adopts PLC programmable logic controller for fully automatic operation without manual intervention |
| Winding Machine Function |
Professionally completes automatic winding and take-up of various tapes and wires, with neat winding and uniform tension |
| Low Power Consumption Design |
Rated power only 100W, extremely low energy consumption, effectively reducing long-term operating costs |
| Standard Voltage Compatibility |
Supports 220V voltage, compatible with power supply standards in most countries and regions worldwide |
| Compact Structure Design |
Dimensions of 60×60×160cm, small footprint for flexible workshop layout |
| Stable Machine Structure |
Total weight of 220kg, solid and stable structure for smooth operation, suitable for long-time continuous operation |
| Stable Production Capacity |
Production capacity reaches 200, meeting small to medium batch production needs |
| Quality Inspection Guarantee |
Provides Mechanical Test Report and Video Factory Inspection to ensure product quality before shipment |
| Comprehensive After-Sales Warranty |
1-year full-machine warranty for peace of mind |
Application Scope
The Automatic Winding Machine is suitable for bundle rope sealing rings and various winding and take-up operations, widely used in the following industries and product categories:
(I) Packaging & Bundling
-
Bundle Rope Sealing Rings – Automatic winding and take-up of various packaging bundling ropes and sealing cords
-
Strapping Bands – Winding and take-up of plastic strapping, PP strapping, and other packaging materials
-
Packaging Wires – Automatic winding and rolling of gift packaging wires and industrial binding wires
(II) Textile & Garment Accessories
-
Sewing Threads – Automatic winding of various sewing threads for garment factory use
-
Embroidery Threads – Automatic winding of embroidery threads for neat and orderly spools
-
Elastic Tapes – Automatic take-up and roll packaging of elastic webbing
-
Webbing – Automatic winding and take-up of various narrow-width webbing
(III) Wires & Cables
-
Wires – Automatic take-up and coiling of electronic wires, power cords, and other wire materials
-
Cables – Automatic winding take-up of communication cables, control cables, and other cables
-
Data Cables – Automatic take-up of USB cables, HDMI cables, and other data cables
(IV) Industrial & Special Purpose
-
Industrial Ropes – Automatic winding of nylon ropes, polypropylene ropes, safety ropes, etc.
-
Rubber Hoses – Automatic take-up and coiling of small rubber hoses
-
Plastic Pipes – Automatic winding and take-up of PE pipes, PVC pipes, and other flexible pipes
Target Customer Groups:
This product is particularly suitable for packaging processing enterprises, textile and webbing factories, wire and cable manufacturers, and various manufacturing workshops requiring automatic winding and take-up operations, meeting the automatic take-up needs of wires, tapes, ropes, pipes, and other materials.
Company Advantages
| Advantage |
Detailed Description |
| Professional Equipment Manufacturing |
Huafang Machinery specializes in the R&D and manufacturing of automatic winding and take-up equipment, with rich industry experience and technical accumulation |
| PLC Intelligent Control |
Core adopts PLC controller for fully automatic operation, simple to operate, reducing labor costs and operational barriers |
| Low Energy & Low Cost |
Rated power only 100W with extremely low energy consumption, helping customers effectively reduce long-term production operating costs |
| Compact & Flexible Structure |
Dimensions of 60×60×160cm with small footprint, flexible deployment in various workshop environments |
| Quality Inspection Guarantee |
Provides Mechanical Test Report and Video Factory Inspection to ensure reliable product quality and customer purchasing confidence |
| Comprehensive After-Sales Service |
1-year full-machine warranty with comprehensive technical support and after-sales maintenance |
| Direct Factory Supply Advantage |
Factory located in Guangdong with complete production supply chain, ensuring quality control and on-time delivery |
|
|
